Product details
The ASUS Prime B450 II Series motherboards provide a stable foundation for your first homebrew system, while offering enough options to grow with your needs. Asus has combined all the good features found
in AMD Ryzen processors with ASUS' core engineering and fundamental design to let you benefit from industry-leading technologies - including automated system optimisation, extensive cooling control and high-quality onboard sound. With an ASUS Prime B450-II series motherboard, PC assembly becomes straightforward - a smart choice.Flexible cooling controlFan-Xpert software provides comprehensive control over system fans. Auto-tuning mode intelligently configures all parameters with a single mouse click. In addition, an Extreme Quiet mode is available, which reduces the enclosure fan speeds below the default set.
Processor family | Ryzen 3 5th Gen, Ryzen 5 5th Gen, Ryzen 7 5th Gen, Ryzen 9 5th Gen |
Memory type | DDR4-RAM |
Internal connection options | M.2 PCI/SATA Combo (1x), S-ATA III (4x), USB 2.0 Header (2x), USB 3.0 Header (1x) |
Peripheral connections | PS/2 Combo, USB 2.0 Type-A (2x), USB 3.2 Gen 1 (4x) |
Item number | 14159410 |
Manufacturer | |
Category | |
Manufacturer no. | 90MB1600-M0EAY0 |
Release date | 9.3.2023 |
Sales rank in Category Motherboards | |
Maximum order quantity | 242 |
Form factor | Micro ATX (mATX) |
Processor socket | AM4 |
Chipset | AMD B450 |
Mainboard features | Clear CMOS Button, COM Port Header, Error Correcting Code, Front panel audio connector, S/PDIF header |
Operating system compatibility | Windows 10, Windows 7 |
Peripheral connections | PS/2 Combo, USB 2.0 Type-A (2x), USB 3.2 Gen 1 (4x) |
BIOS type | UEFI AMI |
Processor family | Ryzen 3 5th Gen, Ryzen 5 5th Gen, Ryzen 7 5th Gen, Ryzen 9 5th Gen |
Memory form factor | DIMM |
Number of pins | 288 x |
Number of memory modules (RAM) | 2 x |
Max. memory (RAM) | 64 GB |
Max. RAM OC | 4400 MHz |
Supported memory speed | 2133 MHz, 2800 MHz, 2933 MHz |
Memory type | DDR4-RAM |
RAM buffer | ECC Registered |
Video connections | HDMI (1x), VGA (1x) |
Video connection version | HDMI 2.0b |
Network connections | RJ45 (1x) |
Ethernet controller brand | Realtek |
Ethernet controller | Gigabit Ethernet |
Max. port speed | 1 Gbit/s |
Chip | Realtek ALC887-VD2 |
Audio channel | 7.1 Channel |
Audio Connections | Audio In |
Internal connection options | M.2 PCI/SATA Combo (1x), S-ATA III (4x), USB 2.0 Header (2x), USB 3.0 Header (1x) |
Expansion slot | PCI Express x1 (2x), PCI Express x16 (1x) |
Number of fan connector | 2 |
Power connectors | 24-pin EATX, 8-pin ATX 12V |
Manufacturer commitment | SBTi |
Scope of delivery | SATA cable - SATA |
Length | 244 mm |
Width | 244 mm |
Height | 259 mm |
Weight | 840 g |
Length | 27.50 cm |
Width | 26.80 cm |
Height | 5.50 cm |
Weight | 858 g |
Specifications may include unverified machine translations.
